Update #2 · Two-Story Braced Steel Frame Study

Member schedule: 86 pieces, 43.3 tons

Every piece in the model, rolled up by piecemark straight from the scene, with weights from the AISC tables (length x lb/ft): - Beams and girders: 58 pieces, 55,220 lb (B1 W18x35, B2 W16x26 infill, G1 W21x44) - Columns: 12 pieces, 17,808 lb (C1 W12x53, 28' long) - Braces: 16 pieces, 13,577 lb (X1 HSS6x6x3/8; 33'-1 1/4" and 28'-7 13/16" diagonals) Total: 86,605 lb, or 43.3 tons, before connections. Plates, bolts and welds come with connection design. Schematic study, not for construction.

Feedback wanted: What would you want on this schedule before pricing it?
